Bamfords 422 Wizzler Mower Spare Parts List

Download the Bamfords 422 Wizzler Spare Parts List in PDF format. This illustrated parts catalogue covers the Bamfords 422 Wizzler, providing exploded component diagrams, original part numbers, descriptions and quantities for identifying replacement parts.

This is a 38-page PDF. The original front cover identifies it as Spare Parts List – Bamfords 422 Wizzler, List No. TP. 614, January 1970, published by Bamfords Ltd of Uttoxeter, Staffs, England. Bamfords 422 wizzler spare part…

The catalogue includes both current and earlier component arrangements, with important distinctions between different patterns and serial-number applications. The original ordering instructions specifically advise quoting the machine's serial number when ordering spare parts. Bamfords 422 wizzler spare part…

What's covered:

• Hitch frame, sub frame, jack stand, transport tube and stabilizer
• Pivot standard, balance spring and lift rod assembly
• PTO input bearing housing
• Gear input shaft assembly
• Gearbox components
• Drive shafts and gearbox gearing
• Drum shaft assemblies
• Drums, knife assembly and saucer assembly
• Drum guard assembly
• Swath deflectors
• Breakaway parts
• PTO drive shaft assemblies
• Tools and transfers
• Old-pattern shrouding board assembly
• Old-pattern guard rail and swath deflectors
• Topping attachment Bamfords 422 wizzler spare part…

The parts list provides detailed breakdowns of the Wizzler's cutting components, including the drums, crop separator bars, knife carriers, knives and saucer assemblies. It also distinguishes between standard and deep saucers and between present- and old-pattern components. Bamfords 422 wizzler spare part…

Several machinery variations are documented. The drum guard assembly, for example, is stated as being fitted to machines from serial number 65103177, while other sections identify parts fitted before or after particular serial-number changes. Bamfords 422 wizzler spare part…

The PTO section is particularly useful when identifying the correct driveline. It covers the present-pattern PTO drive shaft fitted from the 1967 season, an old-pattern PTO shaft fitted up to the early part of the 1967 season, a version used on a limited number of 1967 machines, and specific PTO drive shaft parts for use with Massey-Ferguson 175 tractors. Bamfords 422 wizzler spare part… Bamfords 422 wizzler spare part… Bamfords 422 wizzler spare part…

A separate section covers the optional topping attachment, including the complete attachment, left- and right-hand height control units, mounting frames, pivot tubes, wheel standards, wheels and associated components. Bamfords 422 wizzler spare part…

This Bamfords 422 Wizzler parts manual is useful for owners, farmers, restorers and agricultural engineers who need to identify original components or determine the correct part number for an existing machine.

Please note: This product is a downloadable PDF spare parts list/parts catalogue only. It is not an operator's, service, workshop or repair manual, and no physical machinery or replacement parts are supplied.
