Vicon CM 216 Disc Mower Operator's Manual

Download the Vicon CM 216 Disc Mower Operator's Manual in PDF format, covering operation, setup, adjustments, safety and routine maintenance for the Vicon CM 216 agricultural disc mower.

The manual identifies the Vicon CM 216 as a disc mower designed for cutting grass, clover and similar green crops. It is tractor-mounted using the hydraulic three-point linkage and operates from the right-hand side of the tractor. Vicon CM 216 operators maual

This is a 32-page PDF operator's manual containing practical instructions for setting up, attaching and operating the mower, together with lubrication and routine maintenance information. The manual itself states that it covers operation, lubrication, maintenance and safety precautions. Vicon CM 216 operators maual

What's covered:

• Safety precautions
• General information about the CM 216 disc mower
• Technical specifications
• Packing and assembly
• Preparing the tractor
• Mounting the mower to the tractor
• PTO shaft attachment and adjustment
• Transport position
• Setting the mower into operating position
• Mowing instructions and cutting-height adjustment
• Mowing on slopes
• Swathboard adjustment
• Shear-bolt safety system
• Knife changing
• V-belt tension and adjustment
• Gearbox and mowerbar oil checks
• Oil filling points and capacities
• Nut and bolt checks
• Lubrication plan
• Optional equipment and extras

The technical information specifies a 2.16 m working width, six mowing discs, 18 knives and a minimum power requirement of 40 hp (30 kW). The mower is designed to operate at a 540 rpm PTO speed. Vicon CM 216 operators maual

Routine maintenance instructions include checking and changing the EP 90 oil in the gearbox and mowerbar, checking fastener torque and lubricating specified points every 10 operating hours. Vicon CM 216 operators maual Vicon CM 216 operators maual

This Vicon CM 216 manual is useful for owners and operators who have purchased a used mower without its original handbook, need replacement operating instructions, or want guidance on correctly setting up and maintaining their machine.

Model covered: Vicon CM 216
Equipment: Agricultural disc mower
Document type: Operator's Manual
PDF length: 32 pages

This product is a digital PDF manual, not a physical Vicon CM 216 mower, printed handbook or replacement part.
